Automatic Balloon Confetti Die Cutter | Multi‑Shape Confetti Making Machine
Description
Balloon Sequin Die Cutting Machine
High-speed automatic die cutter for PET laser film, PVC foil, aluminum foil and colored paper — producing round, star, heart and custom-shaped confetti sequins for balloon filling, party decor and wedding supplies.
Speed control Auto Feeding & Rewinding ±0.1mm Precision Quick Die Change 220V / 380V
Product Overview
[
]
]The Balloon Sequin Die Cutting Machine is a purpose-built high-speed die-cutting system designed for manufacturers of balloon-fill confetti, party sequins and decorative foil pieces.
It processes roll-fed materials including PET laser film, PVC colored film, aluminum foil and colored tissue paper, and punches out circles, five-point stars, hearts, polygons and any custom shape via interchangeable steel-rule dies.
Finished sequins drop automatically into a collection tray while the waste web is rewound — delivering clean, burr-free pieces at factory throughput with minimal manual handling.
Key Features
Quick Die Change
Tool-free die mounting; switch between circle, star, heart and custom shapes in minutes, ideal for multi-SKU production.
Precision Feeding
Servo-driven roll feeding with web guiding ensures ±0.1mm accuracy, uniform piece size and zero material waste.
Auto Collection
Cut sequins fall directly into a removable collection tray; waste film is automatically rewound — no manual sorting.
Adjustable Pressure
Die-cutting pressure is finely adjustable for thin aluminum foil (no crushing) through thick paper (clean through-cut).
Safety Protection
Equipped with safety guards, emergency stop button and overload protection — one-touch shutdown in any anomaly.
PLC Touch Control
Intuitive HMI touchscreen with batch counter, preset stop, single/continuous mode — easy for new operators.
Technical Specifications
| Parameter | Specification |
|---|---|
| Compatible Materials | PET laser film, PVC film, aluminum foil, colored tissue paper |
| Material Thickness | 0.02 – 0.30 mm |
| Feeding Method | Automatic roll feeding with 8 unwinders |
| Feeding Accuracy | ±0.1 mm |
| Sequin Size Range | 3 – 50 mm (custom die available) |
| Sequin Shapes | Circle, star, heart, polygon, custom |
| Control System | inverter |
| Operation Modes | continuous die cutting |
| Power Supply | 220V / 380V, 50–60 Hz |
| Main Structures | Unwinder → web guide → die-cut press → collection tray → waste rewinder → electric cabinet |
| Frame Construction | Heavy-duty steel welded frame |
| Safety Devices | Safety guard, emergency stop, overload protection |
Photo suggestion: Close-up of the HMI touchscreen showing the control interface; a dimensioned side-view line drawing of the machine with key parts labeled (unwinder, die station, collection tray, rewinder).
Operation Workflow
1
Pre-Check
Inspect power, lubrication, die condition; reset E-stop
2
Load Material
Mount roll on unwinder, thread through guide rollers, set tension
3
Install Die
Mount die, align position, adjust pressure, test-punch samples
4
Set Parameters
no need,easy operation
5
Run Production
Start auto mode; sequins drop into tray, waste rewinds
6
Finish & Clean
Stop machine, collect finished sequins, clean die and table
Applications
🎈
Balloon Filling
Confetti for latex & foil balloons
🎉
Party Supplies
Birthday, graduation, festival decor
💍
Wedding Decor
Table scatter, invitation inserts
📦
Craft & Packaging
Gift box filler, DIY craft materials
Photo suggestion: Lifestyle collage — 4 images showing finished sequins in balloons, scattered on a party table, inside a wedding invitation, and filling a gift box. Helps buyers visualize end-product value.
Maintenance & Care
Daily
• Clean surface, die area and collection tray of film debris
• Lubricate guide rails and transmission links
• Inspect die sharpness and edge condition
Weekly
• Clean feed rollers of adhesive residue
• Check belt tension and fastener torque
• Verify web-guide alignment calibration
Monthly
• Inspect all electrical connections for looseness
• Check pneumatic/hydraulic pressure (if equipped)
• Test emergency stop and safety interlock
Long-Term Storage
• Apply anti-rust oil to die and metal surfaces
• Cover machine with dust sheet
• Store in dry, ventilated area away from moisture
FAQ
What materials can this machine cut?
It handles PET laser film, PVC colored film, aluminum foil and colored tissue paper from 0.02mm to 0.30mm thick. For materials outside this range, please contact us for a custom evaluation.
Can I use my own custom-shaped die?
Yes. The machine accepts standard steel-rule dies. We can also supply custom dies based on your shape drawing or sample — typical lead time is 3–5 working days.
What is the production capacity?
Output depends on sequin size and material. For standard 10mm round PET sequins, the machine can produce tens of thousands of pieces per hour. We can provide a capacity calculation based on your specific product.
Is installation and training provided?
Yes. The machine comes with a detailed English manual and operation video. We offer remote video guidance for setup and operator training. On-site installation can be arranged at additional cost.
What is the warranty period?
The machine carries a 12-month warranty covering manufacturing defects (excluding consumable parts such as dies and blades). Extended warranty and spare-parts packages are available.
Do you support OEM / custom branding?
Yes. We support OEM branding on the machine, custom voltage/plug configurations, and modified specifications for specific production needs. Minimum order quantities apply for OEM.
Ready to Boost Your Sequin Production?
Contact us today for a customized quotation, free sample cutting test, and detailed capacity analysis.
Get a Quote Now
