Vacuum Bag Making Machine Manufacturer & Supplier | Food & Storage Vacuum Pouches
- Three sides sealing
- Ecomony price
- Small land
- Can be two unwinder rolls
- Can add folding device for printed bag
- Can add rolling device for rolling bag
Description
XUANHAI MACHINE
Manufacturer Since 1988 · 30+ Export Markets
Vacuum Bag Making Machine
Manufacturer & Factory-Direct Supplier
Ruian Xuanhai Machine engineers and manufactures industrial vacuum bag making machines for food-grade vacuum packaging, compression storage bags, and high-barrier pouch production — with factory-direct pricing, full technical support, and global export experience.
Overview
What Is a Vacuum Bag Making Machine?
A vacuum bag making machine is industrial equipment that automatically forms, seals, and cuts vacuum-sealable pouches from roll-stock laminated films. The resulting bags are engineered to withstand the pressure differential of vacuum sealing — keeping food, medical devices, and industrial components protected from oxygen, moisture, and contamination.
Unlike standard pouch-making equipment, vacuum bag machines must produce seals with superior integrity: typical peel strength exceeds 35 N/15mm to maintain airtight closure under vacuum conditions. At Xuanhai, our vacuum bag production lines are built around servo-driven tension control and precision heat-sealing systems that guarantee consistent seal quality at production speeds of up to 150 bags per minute.
Why seal integrity matters more than speed
A vacuum bag with even a micro-leak defeats its purpose entirely. Xuanhai machines use dual-cooling seal technology and inline tension monitoring to ensure seal uniformity across every roll change — the most common point of failure in competitor machines.
Product Range
Types of Vacuum Bag Making Machines We Manufacture
3-Side Seal Vacuum Pouch Machine
Produces flat vacuum pouches sealed on three sides, used for food vacuum packaging, retort pouches, and industrial part protection. Compatible with PA/PE and AL/PE structures.
Most PopularVacuum Compression Storage Bag Machine
Makes household and travel vacuum compression bags (space-saver bags) with valve holes for manual or pump-assisted air removal. PA+PE and PET+PE compatible.
Consumer GoodsStand-Up Vacuum Zipper Pouch Machine
Combines stand-up pouch structure with vacuum-compatible materials and optional zipper insertion. Ideal for resealable vacuum food pouches (nuts, coffee, pet food).
Food RetailHigh-Barrier Retort Pouch Machine
Produces retort-grade vacuum pouches that can withstand high-temperature sterilization (121°C+). Used for shelf-stable ready meals, seafood, and medical packaging.
Pharma / FoodTechnical Data
Key Technical Specifications
Standard parameters across Xuanhai vacuum bag making machines. Custom configurations are available on request.
| Parameter | Standard Range | Notes |
|---|---|---|
| Bag Width | 100 – 600 mm | Custom tooling available |
| Bag Length | 80 – 800 mm | Servo-controlled cut length |
| Production Speed | 60 – 150 pcs/min | Depends on bag size & film |
| Film Thickness | 60 – 200 µm | PA/PE, PET/PE, AL/PE |
| Sealing Temperature | 100 – 280 °C | 6-zone independent control |
| Max Roll Diameter | φ 600 mm | Auto tension correction |
| Seal Strength | ≥ 35 N / 15 mm | Per GB/T 15171 standard |
| Drive System | Dual servo motor | Panasonic / Mitsubishi |
| Control System | PLC + 7" HMI Touch | Recipe storage up to 99 jobs |
| Power Supply | 380V / 50Hz / 3-phase | Customizable for export markets |
Material Compatibility
Compatible Films for Vacuum Bag Production
Choosing the right laminated film structure is critical for vacuum bag performance. The table below compares the four main film types our machines process:
| Film Structure | O₂ Barrier | Puncture Resistance | Best For |
|---|---|---|---|
| PA / PE (Nylon)Recommended | Excellent | Excellent | Food vacuum, retort |
| PET / PE | Good | Very Good | Food, compression bags |
| AL / PE (Foil) | Outstanding | Good | Pharma, light-sensitive |
| OPP / CPP | Moderate | Moderate | Short shelf-life snacks |
Note for buyers: PA/PE (Nylon/Polyethylene) is the industry gold standard for true vacuum packaging. Its molecular structure resists oxygen permeation 10× better than plain PE, while its flexibility prevents seal cracking under vacuum stress. We recommend PA/PE for any application where extended shelf life under vacuum is required.
Production Process
How a Vacuum Bag Making Machine Works
1
Film Unwinding & Tension Control
Roll-stock laminated film feeds from the unwind station. Servo-driven tension control with magnetic powder brakes ensures consistent feed speed regardless of roll diameter, preventing wrinkles that cause seal defects.
2
Film Folding or Side-Seal Alignment
For 3-side seal bags, the film is folded into a U-channel. For flat vacuum bags, two separate film webs are precisely aligned. Photoelectric tracking ensures edge alignment to ±0.5 mm.
3
Side Sealing (Longitudinal)
Heated seal bars close on both lateral edges with precisely calibrated temperature and dwell time. The seal bar width can be set from 8–20 mm depending on bag application.
4
Bottom / Cross Sealing & Cooling
The bottom seal is formed by a cross-seal jaw with integrated cooling. The dual heat-cool cycle — a Xuanhai-engineered feature — reduces seal crystallization and improves peel strength consistency by up to 18%.
5
Precision Cutting
A servo-synchronized cutter separates finished bags. Cut length is set via the HMI and automatically adjusted by a photoelectric color-mark sensor for printed films.
6
Optional: Valve Punching / Zipper Insertion
For compression storage bags, a valve hole is punched and reinforced. For resealable vacuum bags, a zipper strip is fed and sealed inline without slowing production speed.
Applications
Industries That Use Vacuum Bags
Our vacuum bag making machines serve manufacturers across a broad range of sectors. Vacuum packaging is chosen wherever shelf life, contamination prevention, or space reduction are primary concerns.
Meat & Seafood Vacuum Packaging
Coffee & Tea (Degassing Valve Bags)
Cheese & Dairy
Snacks & Nuts
Ready Meals (Retort Pouches)
Medical Device Packaging
Pharmaceutical Blister Alternatives
Household Compression Storage Bags
Electronic Component Protection
Pet Food Vacuum Bags
Industrial Parts Anti-Rust Packaging
Why Choose Us
What Sets Xuanhai Apart From Other Vacuum Bag Machine Suppliers
36+ Years Manufacturing Experience
30+ Countries Served
200+ Engineers & Technicians
Most vacuum bag machine suppliers in China are trading companies reselling third-party equipment. Xuanhai is a direct factory — our machines are designed, assembled, and tested at our 8,000 m² plant in Ruian, Zhejiang, China. This means every customization request (bag size, film compatibility, optional modules) is handled in-house without margin stacking.
Engineering Differentiators
Dual-cooling seal technology. Competitors use single-phase cooling. Our machines apply two sequential cooling passes after heat sealing, reducing residual heat distortion in thin PA/PE films and increasing seal strength consistency across ambient temperature changes — a critical factor for customers operating in tropical climates.
Recipe memory system. Our PLC stores up to 99 bag-type recipes. Operators switch between vacuum bag types (size, temperature profile, cut length) in under 60 seconds without manual calibration, dramatically reducing changeover waste.
Real-time tension feedback. Rotary encoders on both the unwind and feed rollers continuously compare actual vs. target tension, making micro-corrections 50 times per second. This eliminates the "accordion effect" — the leading cause of edge-seal defects in high-speed bag production.
Xuanhai vs. Typical Market Alternatives
| Feature | Xuanhai | Trading Co. (OEM Reseller) | Budget Manufacturer |
|---|---|---|---|
| Direct factory pricing | ✓ | ✗ (mark-up) | ✓ |
| Custom bag size tooling | ✓ In-house | Limited | Limited |
| Dual-cooling seal system | ✓ Standard | Rare | Not available |
| Servo tension control | ✓ Dual servo | Varies | Single servo |
| Export experience | ✓ 30+ countries | Varies | Limited |
| On-site installation support | ✓ Available | ✗ | Rare |
| Spare parts availability | ✓ Stocked | Third-party | Varies |
FAQ
Frequently Asked Questions
What is a vacuum bag making machine?
A vacuum bag making machine forms, seals, and cuts vacuum-sealable pouches from laminated film rolls. The resulting bags are used to vacuum-pack food, medical devices, household items, and industrial components. Production speeds range from 60 to 150 bags per minute depending on model and bag dimensions.
What is the best film material for vacuum bags?
PA/PE (Nylon + Polyethylene) laminate is the industry standard for true vacuum packaging. It offers excellent oxygen barrier properties, outstanding puncture resistance, and flexibility under vacuum stress. PET/PE is a cost-effective alternative for shorter shelf-life applications or vacuum compression bags.
Can the machine make both food and non-food vacuum bags?
Yes. Xuanhai vacuum bag making machines are film-agnostic by design. By changing the seal temperature profile and film type, the same machine can produce food-grade vacuum pouches, medical device pouches, industrial anti-rust bags, and household compression bags. We provide pre-set recipes for each application.
What is the minimum order for a custom vacuum bag machine?
We supply single machines with full custom configuration — there is no minimum order quantity for equipment. For spare parts and tooling components, minimum orders may apply. Contact our sales team for a detailed quotation based on your bag specifications.
Do you provide installation and operator training?
Yes. All Xuanhai machines ship with multilingual operation manuals and wiring diagrams. Remote video commissioning is standard. On-site installation by our technicians is available for international orders — typically 3–5 days on-site, including operator training and production sign-off. Costs and availability discussed at quotation stage.
How long does delivery take?
Standard-configuration vacuum bag making machines are shipped within 25–35 working days from order confirmation and deposit receipt. Custom configurations with special tooling or module additions may require 40–50 working days. We ship by sea (FCL/LCL) or air freight depending on urgency and machine size.
What vacuum bag sizes can the machine produce?
Our standard platform covers widths from 100 mm to 600 mm and lengths from 80 mm to 800 mm. Bags outside this range require a custom frame and sealing unit, which we manufacture in-house. Please provide your target bag dimensions when requesting a quotation.
Ready to Start Producing Vacuum Bags?
Share your bag dimensions, target output, and film type — our engineers will recommend the right vacuum bag making machine configuration and provide a factory-direct quote within 24 hours.
